ESS C-type connectors, 100A to 200A

Chassis-mount feedthrough terminals for battery packs and energy-storage enclosures. Compare four current ratings, review the supplied technical data and send your requirements to our international sales team.

Request bulk pricing Compare models

Red and black · Nickel-plated brass terminals · V-0 nylon housing

Supplied photograph of the red and black EVTOP ESS C-type connectors

Choose your current rating

The table summarises the supplied C-type specification sheet. Match your system requirements to the model, then confirm cable, busbar, enclosure and installation requirements with EVTOP.

ESS C-type model comparison from the supplied technical specification
Model	Continuous current	Terminal screws	Reported test rise
C-100	100A	M5 + M5	26.1 °C rise @ 100A
C-120	120A	M6 + M6	35.4 °C rise @ 120A
C-150	150A	M8 + M6	31.2 °C rise @ 150A
C-200	200A	M8 + M6	39.2 °C rise @ 200A

Test results depend on the conditions in the specification. The listed 2200 V AC withstand test is not a continuous operating-voltage rating.

Download the ESS C-type technical specification (PDF)

ESS C-100 Connector

100A C-type chassis-mount connector, available in red and black

Specifications & pricing

ESS C-120 Connector

120A C-type chassis-mount connector, available in red and black

Specifications & pricing

ESS C-150 Connector

150A C-type chassis-mount connector, available in red and black

Specifications & pricing

ESS C-200 Connector

200A C-type chassis-mount connector, available in red and black

Specifications & pricing

Planning a battery or solar-storage assembly?

C-type terminals provide a bolted electrical connection through an enclosure. Selection involves more than the current rating: check the mounting dimensions, terminal arrangement, conductor size, insulation and environment for your assembly.
